OUR PRODUCTS
XVR4104HS-I
4CH Penta-brid 1080N/720P Compact 1U 1HDD WizSense Digital Video Recorder
* The information below only applies to hardware version 2.0 of the product.
> 4-channel SMD Plus for analog channels which allows the device to trigger accurate alarms for humans and vehicles.
> 4-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos.
> Supports HDCVI, AHD, TVI, CVBS and IP video input.
> Supports up to 5-channel IP camera input and each channel can be up to 2 MP. The incoming bandwidth reaches 32 Mbps.
> Smart H.265+ and H.265 dual-stream video compression.
XVR7216A-4KL-X
Dahua XVR7216A-4KL-X pro series penta-brid 4K uhd 16ch@8Mpx 5IN1 HDCVI/AHD/HDTVI/PAL/IP h.265+ p2p alarm ivs iot
- Standard CCTV Technology Support: CVBS/HDCVI/HDTVI/AHD + IP@8Mpx (Max. 16 IP) Onvif 16.12
- HDCVI Camera resolution: 4K@7fps, 6Mpx@10fps, 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- AHD Camera resolution: 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- HD-TVI Camera resolution: 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- Video signal transmission over long distances (800-1100m), using coaxial cable.
- Management by XVR via coax cable. the OSD and PTZ camera movement.
- Recording (REC & Live) on all channels in 4K ULTRA HD.
- Video compression H.265+/H.265/H.264+/H.264 dual-stream
- 1/4/8/9/16 channels (IP extension not active) or 1/4/8/9/16/25 (active IP extension), GRID interface and intelligent search
- 3D intelligent positioning with Dahua PTZ dome camera - RS485 port for classical analog PTZs.
- Support and Programming of SMART & Video Analysis IVS : Tripwire, Intrusion (for all channels), Abandoned / Missing, Face Detection. (Crossing lines | Intrusion in the air | Abandoned object | Detecting faces). Programmable on all channels (up to 10 rules per channel (Max.4)). Face Detection (on the first channel only) and Smart Search.
- POS Function (Point of Sale Terminal): This funcion includes POS ticket information overlay and search which can be widely used in retail program.
- IoT Functionality: HDCVI IoT can achieve multi-dimensional surveillance by integrating sensors with monitoring video, which not only can generate the report for analysis but also prevent risk in advance.
- New simplified and intelligent graphical interface (version HDCVI 5.0) - Smart Fan / Coax. Audio functions.
- It Supports 2 SATA HDD up to 10TB, 2 USB Ports (1 USB 2.0 , 1 USB 3.0)
- Supports 4 Input / 1 Output RCA Audio - Two-way Talk.
- 16 inputs + 3 relay alarm outputs
- Multiple network monitoring: Web viewer, CMS (DSS / PSS Smart) Smartphone (DMSS)
- Easy Setup P2P QR scan with Cloud service dedicated Dahua.
- ONVIF Version 16.12, CGI Conformant
